IC 447



Click the image for a larger view. (1800 x 1200 - 1.17 MB)

Instrument

Takahashi FSQ-106ED @ f/5.0 (530 mm F.L.) Captured at 2.1 arcsec/pixel.  Shown at 3.90 and 9.35  arcsec/pixel.

Mount

Paramount MyT

Camera

SBIG STF-8300M Self Guiding Package w/ mono ST-i, using AstroDon E-Series LRGB filters.

Acquisition Data

2/27/2016 to 3/11//2016  Chino Valley, AZ with CCD Commander & CCDSoft.

Exposure

Lum

 320 min. (32 x 10 min.)      bin 1x1

RGB

 360 min. (12 x 10 min. each)     "

 RGB ratios are 1.00, 0.93, 0.94

Software

  • CCDSoft, PixInsight & Photoshop CS6.

  • A standard image-train calibration was used, as determined by eXcalibrator v4.36, and then adjusted for altitude extinction.

  • PixInsight processing includes calibration, registering, stacking, LRGB creation, gradient removal and non-linear stretching with HistogramTransformation.

  • PhotoShop for the final touch up.

  • Noiseware 5, a PhotoShop plug-in.

Comment

North is to the right.

This beautiful complex of reflection and dark nebulae is in the constellation Monoceros. The large blue reflection nebula is IC 447. To the right and seemingly connected by a dark nebula is IC 446. This blue reflection nebula also shows glowing yellow dust. Above are reflection nebula NGC 2245 and further up is NGC 2247. NGC 2245 is also showing strong yellow dust. At the upper left corner is the red glow of the nearby Cone Nebula.
