Instrument |
Takahashi FSQ-106ED @
f/5.0 (530 mm F.L.) Captured at 2.1 arcsec/pixel. Shown at 4.28
and 17.10 arcsec/pixel. |
|
Mount |
Paramount MyT |
|
Camera |
SBIG STF-8300M Self
Guiding Package w/ mono ST-i, using AstroDon E-Series LRGB filters. |
|
Acquisition Data |
5/20/2017 to 6/27/2017
Chino Valley, AZ w/ CCD Commander, TheSkyXpro and CCDSoft |
|
Exposure |
|
This is a four
panel mosaic.
The exposures are
duplicated for each panel. |
|
Lum |
120 min. (12 x
10 min.) Binned 1x1 |
|
RGB |
240 min. (
8
x 10 min. each) " |
|
|
Software |
-
PixInsight &
PhotoShop
-
eXcalibrator v5.1 for
(g:r)
color balancing, using 564 stars from the APASS database.
-
PixInsight
processing includes calibration, registering, stacking, LRGB
creation, mosaic creation, gradient removal with
DynamicBackgroundExtraction and non-linear stretching
with HistogramTransformation.
-
Noiseware 5, a
PhotoShop plug-in.
-
PhotoShop processing includes
background noise reduction and dimming the stars.
|
|
Comment |
North is to the
bottom. Up-side-down it looks like a horse.
IC 4592 (also known as
the Blue Horsehead Nebula) is a reflection nebula in the
constellation Scorpius at a distance of about 400 light-years.
The nebula is illuminated by the bright star, Nu Scorpii. |
|
