M16 in Mapped Color



Click the image for a wide field 1.28 arcsec/pixel display.

Instrument

12.5" RCOS @  ~f/9 (2880 mm fl) 0.64 arcsec / pixel.  Shown resampled to 2.56 arcsec/pixel.

Mount

Paramount ME

Camera

SBIG STL-11000 w/ internal filter wheel, AstroDon Filters

Acquisition Data

5/26/2008 and 6/3/2008  Chino Valley... with CCDAutoPilot3

Exposure

SII   450  min.  (15 x 30 min. bin 1x1)

Ha    300 min.  (10 x 30 min. bin 1x1)
OIII  300 min   (10 x 30 min. bin 1x1)

Ha & SII was combined for the luminance

SII,Ha & OIII mapped to RGB respectivly

Software

CCDSoft, CCDStack, Photoshop CS w/ the Fits Liberator plugin and Noel Carboni's actions.

CCDStack to register, normalize, data reject & combine.

PhotoShop for non-linear stretching, sharpening and color combine.

Comment

North is to the top.
The Eagle emission nebula, also known as M16 or NGC 6611, lies about 6500 light years away, spans about 20 light-years, and is visible with binoculars toward the constellation of Serpens.

This false color image was acquired with SII, Ha and OIII filters mapped to the RGB channels respectively. So in this image Red indicates the presence Sulfur, Green Hydrogen and Blue for Oxygen.
