Click the image for a ~ 50%
size view. (1600 x 1200 - 1.15 MB)
|
Instrument |
Takahashi FSQ-106ED @
f/5.0 (530 mm F.L.) Captured at 2.1 arcsec/pixel. Shown at
4.31 and 9.21 arcsec/pixel. |
|
Mount |
Paramount MyT |
|
Camera |
SBIG STF-8300M Self
Guiding Package w/ mono ST-i, using AstroDon E-Series LRGB filters. |
|
Acquisition Data |
10/22/2016 to
11/25/2016
Chino Valley, AZ with CCD Commander & CCDSoft. |
|
Exposure |
|
Lum |
1730 min. (173
x 10 min. each) binned 1x1 |
|
RGB |
720 min. (24
x 10 min. each) " |
RGB
combine ratios are 1.00,
0.98, 0.92 |
|
Software |
-
PixInsight & Photoshop CS6.
-
eXcalibrator v5.0 for
(g:r)
color balancing, using 307 stars from the SDSS-DR9 database.
-
PixInsight
processing includes calibration, registering, stacking, LRGB
creation, gradient removal and non-linear stretching
with HistogramTransformation .
-
Noiseware 5, a
PhotoShop plug-in.
-
PhotoShop for
final touch up.
|
|
Comment |
North is to the
top.
|
|
