5
|
Click the image for a 75% size
wider view. (2841 x
1776 - 1.13 MB)
|
Instrument |
12.5" RCOS @
~ f/9 (2880 mm fl) at 0.64 arcsec/pixel. Shown at 0.85 and
1.55 arcsec/pixel. |
|
Mount |
Paramount ME |
|
Camera |
SBIG STL-11000 w/
FW8 filter wheel & AstroDon Gen-2 LRGB filters. |
|
Acquisition Data |
4/12/2015 to
4/2/2016 Chino Valley, AZ. with CCD Commander & CCDSoft. AOL
guided |
|
Exposure |
|
Lum |
465 min (31 x
15 min. each) Bin 1x1 |
|
RGB |
900 min (20 x
15 min. each) Bin 2x2 |
eXcalibrator RGB ratios are 1.00,
0.81 & 0.93 |
|
Software & Processing Notes
|
-
CCDSoft, CCDStack,
PixInsight, Photoshop CS6.
-
eXcalibrator
v5.0 for (g:r) color balancing, using
43 stars from the SDSS-DR9 database.
-
CCDBand-Aid to repair
KAI-11000M vertical bars.
-
CCDStack to
calibrate all sub exposures.
-
PixInsight to
register, normalize, data reject, combine the sub
exposures, gradient removal, non-linear stretching with HistogramTransformation and to create the LRGB image. HDRMultiscaleTransform to enhance the detail
at the galaxy core.
-
Noiseware 5, a PhotoShop plug-in.
-
PhotoShop final touch-up
includes background noise reduction and selective sharpening.
|
|
Comment
|
North is to the top.
M95 (NGC 3351) is a
barred spiral galaxy about 50 million light-years away in the
constellation Leo. It was discovered by Pierre Méchain in 1781, and
catalogued by Charles Messier four days later.
|
|
