Instrument |
12.5" RCOS @ ~f/9
(2880 mm fl) at 0.64 arcsec/pixel. Shown at 0.85 and 1.28 arcsec/pixel. |
|
Mount |
Paramount ME |
|
Camera |
SBIG STL-11000 w/
FW8-STL filter wheel, AstroDon Gen II LRGB Filters. |
|
Acquisition Data |
4/14/2015 to 5/20/2015 Chino Valley, AZ... with CCDAutoPilot5
& CCDSoft. AOL guided. |
|
Exposure |
|
Lum |
465
min. (31 x 15 min. bin 1x1) |
|
RGB |
360 min. ( 8 x
15 min. each bin 2x2) |
RGB ratios are 1.00,
1.06 & 1.29 |
|
Software |
-
CCDSoft, CCDStack,
Photoshop CS6, PixInsight and Noel Carboni's actions.
-
eXcalibrator
v4.36 for (g:r) color balancing, using 96 stars from the
SDSS-DR9 database.
-
CCDBand-Aid
to repair
KAI-11000M
vertical bars.
-
CCDStack to
calibrate all sub exposures, register and stack the color and create the RGB image.
-
PixInsight
processing includes registering and stacking the luminance,
gradient repair, non-linear stretching with HistogramTransformation,
HDRMultiscaleTransform and LRGB creation.
-
PhotoShop for the final
touch-up.
-
Noiseware 5, a PhotoShop plug-in.
|
|
Comment |
North is to the
bottom. Because of the available guide star, the image looks
better upside-down.
NGC 5792 is a a
barred, ringed spiral galaxy about 94 million light-years away in
the constellation Libra.
|
|
