NGC 6217



































Click the image for an uncropped 75% size view. (2700 x 1800 - 1.12 MB)

Instrument

12.5" RCOS @ ~ f/9 (2880 mm fl) at 0.64 arcsec/pixel. Shown at 0.86 and 1.28 arcsec/pixel.

Mount

Paramount ME

Camera

SBIG STL-11000 w/ FW8 filter wheel, AstroDon Gen-2 filters.

Acquisition Data

6/19/2015 to 7/20/2015 Chino Valley, AZ.  with CCD Commander & CCDSoft.  AOL guided

Exposure

Lum

525 min (35 x 15min) Bin 1x1

RGB

540 min (12 x 15 min. each channel) Bin 2x2

eXcalibrator RGB ratios are 1.00, 0.98 & 1.14

Software & Processing Notes

  • CCDSoft, CCDStack, PixInsight, Photoshop CS6.

  • eXcalibrator v4.36 for (g:r) color balancing, using 104 stars from the SDSS-DR7 database.

  • CCDBand-Aid to repair KAI-11000M vertical bars.

  • CCDStack to calibrate all sub exposures and create the RGB image.

  • PixInsight to register, normalize, data reject, combine the luminance sub exposures, gradient removal, non-linear stretching with HistogramTransformation, detail enhancement with HDRMultiscaleTransform and to create the LRGB image.

  • PhotoShop for the final touch-up.

  • Noiseware 5, a PhotoShop plug-in.

Comment

The galaxy is shown rotated 135 clockwise.

NGC 6217 is a barred spiral galaxy in the constellation Ursa Minor at a distance of about 60 million light-years.

At the top right edge of the image is the interesting interacting galaxy UGC 10509. This galaxy is about 70 million light years from Earth.
