NGC 7789 - Open Cluster



Click the image for a 46% size view. (1800 x 1200 - 1.03 MB)

Instrument

12.5" RCOS @ ~ f/9 (2880 mm fl) at 0.64 arcsec/pixel. Shown at 1.38 and 3.33 arcsec/pixel.

Mount

Paramount ME

Camera

SBIG STL-11000 w/ FW8 filter wheel, AstroDon Gen-2 filters.

Acquisition Data

9/12/2015 to 9/19/2015 Chino Valley, AZ.  with CCD Commander & CCDSoft, AOL guided.

Exposure

RGB

540 min. (12 x 15 min. each channel) Bin 1x1

RGB ratios are 1.00, 0.95 & 1.05

Software & Processing Notes

  • CCDSoft, CCDStack, PixInsight, Photoshop CS6.

  • No SDSS stars were available for color balancing, so a standard image-train color calibration was used, as determined by eXcalibrator v4.25, and then adjusted for altitude extinction.

  • CCDBand-Aid to repair KAI-11000M vertical bars.

  • CCDStack to calibrate the sub exposures.

  • PixInsight to register, normalize, data reject, combine the sub exposures, create the RGB, gradient removal and non-linear stretching with HistogramTransformation.

  • PhotoShop for the final touch-up.

Comment

The cluster is shown rotated 10 clockwise.

M103, or NGC 581, is an open cluster in the constellation Cassiopeia. It was discovered by Charles Messier in 1781. At about 9000 light years, it is one of the most distant known open clusters.
