NGC 90 & More



Annotation by Astrometry.net

Click the image for a higher resolution view. (1800 x 1200 - 927 KB)

Instrument

12.5" RCOS @  ~f/9 (2880 mm fl) at 1.28 arcsec/pixel. Shown at 2.06 and 0.87 arcsec/pixel.

Mount

Paramount ME

Camera

SBIG STL-11000 w/ FW8 filter wheel, AstroDon Gen-2 Filters

Acquisition Data

10/22/2014 to 11/26/2014 Chino Valley, AZ... with CCD Commander & CCDSoft, AOL guided.

Exposure

Lum

450 min. (30 x 15 min. each)  Bin 1x1

RGB

900 min. (20 x 15 min. each)  Bin 2x2

eXcalibrator RGB ratios are 1.00, 0.95 & 1.09

Software & Processing Notes

  • CCDSoft, CCDStack, PixInsight & Photoshop CS6.

  • eXcalibrator v4.30 for (g:r) color balancing, using 51 stars from the SDSS-DR9 database.

  • CCDBand-Aid to repair KAI-11000M vertical bars.

  • CCDStack to calibrate all sub exposures and and creating the RGB image.

  • PixInsight processing includes registration, stacking and data rejection for the luminance, gradient repair and non-linear stretching, with HistogramTransformation, for both the Lum and RGB images and creating the LRGB image. Finally, selective use of HDRMultiscaleTransform, with various layer counts, was used to enhance the detail of the galaxies.

  • PhotoShop for the final touch up.

  • Noiseware 5, a PhotoShop plug-in.

Comment

North is to the top.



This interesting group of galaxies is located in the constellation Andromeda. The galaxy distances generally fall in the range of 220 to 260 million light years.
