Instrument |
Takahashi FSQ-106ED @
f/5.0 (530 mm F.L.) Captured at 3.5 arcsec/pixel. Shown
resampled to 16.8 arcsec/pixel. |
|
Mount |
Paramount ME |
|
Camera |
SBIG STL-11000 w/
internal filter wheel, AstroDon 6nm Filters |
|
Acquisition Data |
9/15/2008
to 9/28/2008 Chino Valley... with CCDAutoPilot3 |
|
Exposure |
SII 420
min. (14 x 30 min. bin
1x1)
Hα
540 min. (18 x 30 min. bin 1x1)
OIII 420 min. (14 x 30 min. bin 1x1)
SII,Ha & OIII are mapped
to RGB respectively
Click
here for a natural color image.
Click
here for an Hα
B&W image |
|
Software |
CCDSoft,
CCDStack, Photoshop CS w/ the Fits Liberator plugin and Noel Carboni's actions.
CCDStack to calibrate, register,
normalize, data reject & combine.
PhotoShop for
non-linear stretching and the color combine. |
|
Comment |
North is to the right.
The colors of this
image more closely follow the Hubble Palette. The presence of
sulfur, hydrogen and oxygen are more clearly shown. Red indicates
the presence sulfur, green hydrogen and blue oxygen. With no
color manipulation, the image would be basically green, due to the
dominance of hydrogen.
There are a lot of objects in this image. Place your mouse
over the image to see labels of the objects.
|
