NGC 7000 & IC 5070


Click the image for a higher resolution (~33%) view. (2196 x 1050 - 1.8 MB)


Takahashi FSQ-106ED @ f/5.0 (530 mm F.L.) Captured at 2.1 arcsec/pixel.  Shown at 4.83 and 14.15 arcsec/pixel.


Paramount MyT


SBIG STF-8300M Self Guiding Package w/ mono ST-i, using an AstroDon 5nm Ha & E-Series RGB filters.

Acquisition Data

Sept-2018 Chino Valley, AZ... with TheSky, CCD Commander & CCDSoft


This is a two panel mosaic.
The exposures are
duplicated for each panel.

 RGB  390 min. (13 x 10 min. bin 1x1)
 Ha  510 min. (34 x 15 min. bin 1x1)

Click here for color mapped narrowband versions.

Click here for the B&W Ha version.

Software & Processing Notes

  • CCDSoft, PixInsight & Photoshop CS6.

  • eXcalibrator v6.1 for (g:r)(b:r) color balancing.

  • PixInsight processing includes calibration,  registration and stacking the Ha & RGB data, creating the mosaic, gradient repair, non-linear stretching with HistogramTransformation, LocalHistogramEqualization.

  • PhotoShop to add the Ha data & final touch-up.


North is to the top.

The emission nebula on the left is famous partly because it resembles Earth's continent of North America. To the right of the North America Nebula, cataloged as NGC 7000, is a less luminous nebula that resembles a pelican dubbed the Pelican Nebula, cataloged as IC 5070. The two emission nebula measure about 50 light-years across, are located about 1500 light-years away, and are separated by a dark absorption cloud. The nebulae can be seen with binoculars from a dark location. Look for a small nebular patch north-east of bright star Deneb in the constellation of Cygnus.
Source:  NASA APOD

More info at Wikipedia: NGC 7000   IC 5070
