Instrument |
Takahashi FSQ-106ED @
f/5.0 (530 mm F.L.) Captured at 2.1 arcsec/pixel. Shown at
4.83 and 14.15 arcsec/pixel. |
|
Mount |
Paramount MyT |
|
Camera |
SBIG STF-8300M Self
Guiding Package w/ mono ST-i, using an AstroDon 5nm Ha & E-Series RGB filters. |
|
Acquisition Data |
Sept-2018 Chino Valley, AZ...
with TheSky, CCD Commander & CCDSoft |
|
Exposure |
|
This is a two panel mosaic.
The exposure is
duplicated for each panel. |
|
Ha |
510
min. (34 x 15 min. bin 1x1) |
Click
here for color mapped narrowband versions.
Click
here for the RGB version. |
|
Software & Processing Notes |
-
CCDSoft, PixInsight & Photoshop CS6.
-
PixInsight
processing includes calibration, registration and stacking, creating the mosaic, gradient repair, non-linear stretching with HistogramTransformation, LocalHistogramEqualization.
-
PhotoShop for the final touch-up.
|
|
Comment |
North is to the top.
The emission nebula on the left is famous partly because it
resembles Earth's continent of North America. To the right of the
North America Nebula, cataloged as NGC 7000, is a less luminous
nebula that resembles a pelican dubbed the Pelican Nebula, cataloged
as IC 5070. The two emission nebula measure about 50 light-years
across, are located about 1500 light-years away, and are separated
by a dark absorption cloud. The nebulae can be seen with binoculars
from a dark location. Look for a small nebular patch north-east of
bright star Deneb in the constellation of Cygnus.
Source: NASA APOD
More info at
Wikipedia:
NGC 7000
IC
5070 |
