NGC 5945

           Click the full screen zoom button       ^
Click the image to Zoom and Pan

Click here to view the image without Zoomify (3600 x 2400)





12.5" RCOS @  ~f/9 (2880 mm fl) 0.64 arcsec / pixel.  Zoomify image scale is 0.64 to 3.08 arcsec / pixel.


Paramount ME


SBIG STL-11000 w/ internal filter wheel, AstroDon Gen I Filters

Acquisition Data

5/16/2010 to 6/9/2010 Chino Valley, AZ... with CCDAutoPilot3 & CCDSoft,  AOL guided


Lum (no filter)  390 min (26 x 15 min, bin 1x1)

RGB                225 min ( 5 x 15 min each, bin 2x2)


  • CCDSoft, CCDStack, Photoshop CS w/ the Fits Liberator plugin. Noel Carboni's actions and Russell Croman's GradientXTerminator.

  • eXcalibrator for (u-g), (g-r) color calibration, using 5 stars from the SDSS7 database.

  • PixFix32 (pre-beta) to repair hot/cold pixels and column defects.

  • CCDStack to calibrate, register, normalize, data reject, combine the sub exposures, LRGB color, and luminance deconvolution.

  • PhotoShop for LLRGB combine &  on-linear stretching.



Object Type

~Dist M Light-Yr

NGC 5945

Barred Spiral Galaxy  270

NGC 5947

Barred Spiral Galaxy 290

NGC 5943

Elliptical/Spiral Galaxy 278

NGC 5934
NGC 5935

Interacting Spiral

UGC 09873

Spiral Galaxy 276

PGC 055238

Spiral Galaxy 272
PGC 055173 Spiral Galaxy 252
MaxBCG J232.17007+42.93827 Galaxy Cluster 3,580

North is ~ to top.  The image is rotated 10░ clockwise.

NGC 5945, along with the other galaxies in the image, are located in the constellation Bo÷tes. NGC 5945 is a beautiful example of a barred galaxy, with two nearly circular spiral arms. The two arms appear to have a high concentration of hot young blue stars. Just above the rings is a blue area, of possibly similar stars, that appear to have become slightly disconnected from the galaxy. This area probably created the oval ring that surrounds the galaxy.

To the far right, of NGC 5945, is a wonderful pair of interacting galaxies... NGC 5934 and 5935.

At the center of the image is the NGC 5943. Closer examination reveals a jet coming from the left side of the galaxy. This jet may be related to the large, and faint, cloud that extends to the upper right and lower left of NGC 5943.

Unfortunately, searching the Internet revealed little information about these galaxies. The above is all speculation by the author... an amateur astronomer.
