NGC 7023 - The Iris Nebula



Click the image for a larger view.


Instrument

Takahashi FSQ-106ED @ f/5.0 (530 mm F.L.) Captured at 2.1 arcsec/pixel.  Shown at 4.2 and 9.38 arcsec / pixel.l.

Mount

Losmandy G11 with Gemini L4 v1.0

Camera

SBIG STF-8300M Self Guiding Package w/ mono ST-i, using Baader LRGB filters.

Acquisition Data

7/31/2013 to 11/32013 Chino Valley, AZ... with CCDAutoPilot5 & CCDSoft.

Exposure

 Lum 450 min. (30 x 15 min. bin 1x1)
 Lum 150 min. (30 x 5 min. bin 1x1)

Red

110 min. (22 x 5 min. each bin 1x1)

 Green 130 min. (26 x 5 min. each bin 1x1)
 Blue 155 min. (31 x 5 min. each bin 1x1)

Software & Processing Notes

  • CCDSoft, CCDStack, PixInsught, Photoshop CS6 and Noel Carboni's actions. .

  • No SDSS stars were available for color balancing, so a standard image-train color calibration was used, as determined by eXcalibrator v4.2, and then adjusted for altitude extinction.

  • CCDStack to calibrate, register, normalize, data reject, combine the sub exposures and create the RGB image.

  • PixInsight for gradient removal and initial non-linear stretching.

  • PhotoShop for the LRGB combine & final touch-up. FreeHDR was used to combine the 15 and 5 minute luminance exposures.

  • Noiseware Pro, a PhotoShop plug-in.

  • Atlantic Light Works FreeHDR, a PhotoShop plug-in.

Comment

The image is rotated 90 degrees clockwise

The Iris Nebula is a bright reflection nebula in the constellation Cepheus, at a distance of about 1,300 light-years. The nebula, LBN 487, surrounds the star cluster NGC 7023. LBN 487 is primarily illuminated by SAO 19158, a hot bluish magnitude 7 star. The characteristic blue color, of the Iris, is a result of blue light being more efficiently scattered by the dust.
