Instrument

12.5" RCOS @  ~f/9 (2880 mm fl) 0.64 arcsec / pixel.  The Zoomify image scale is 0.85 to 1.70 arcsec / pixel.

Mount

Paramount ME

Camera

SBIG STL-11000 w/ internal filter wheel, AstroDon 6nm Ha Filter

Acquisition Data

1/19/2011 to 3/28/2011 Chino Valley, AZ... with CCDAutoPilot3 & CCDSoft.  AOL guided

Exposure

Hα    510 min. (17 x 30 min. bin 1x1)

Click here for the RGB color image.

Click here for narrow band color mapped images.

Software

• CCDSoft, CCDStack, Photoshop CS w/ the Fits Liberator plugin, Noel Carboni's actions and Russell Croman's GradientXTerminator.

• PixFix32 (pre-beta) to repair column defects.

• CCDStack to calibrate, register, normalize, data reject, combine the sub exposures.

• PhotoShop on-linear stretching.

North is to the top

Jones-Emberson 1 (PK 164+31.1) is a 14th magnitude planetary nebula in the constellation Lynx, at a distance of 1600 light years. It is a larger planetary with low surface brightness. The 16.8-magnitude central star is very blue white dwarf.

Source: Wikipedia
